IN-LINE QUALITY CONTROL
WINDOW TESTING MACHINE

Designed and assembled in Canada from corrosion resistant aluminum, stainless steel and polycarbonate.



NON-DESTRUCTIVE WINDOW TESTING

  1. ROLL WINDOW IN

  2. CLAMP

  3. TEST

  4. ROLL WINDOW OUT

  • The system of choice for quality control end of production line window testing on windows, doors, skylights and curtain walls.

  • Water spray is contained between the test specimen and test wall maintaining a dry shop or lab environment. The test station sits in a stainless steel water tank, and uses a pump and filter to recirculate water to the spray nozzles.

  • Simulates wind driven rain in accordance with a variety of widely-accepted test standards.

  • Used by manufacturers and test laboratories in North America and throughout the world.

  • Testing is entirely non-destructive; successfully tested samples can be shipped to the customer or be returned to inventory in perfect condition.

  • Conveyor roller system ensures safe and easy loading and unloading of samples.

  • Unique gasket and pneumatic clamping system eliminates the need for wooden test fixtures (often referred to as wooden “bucks”).

  • TesPro spray nozzles are individually controlled and ensure complete coverage on test samples.

  • Includes calibrated pressure meter for measuring test pressures.

  • Includes a 1 year warranty.

  • Includes water spray catch box for spray calibration.

  • Machine setup time is less than two hours after unloading!

  • Training available - contact us for details.





Automated window testing machine
AUTOMATED WINDOW TESTING MACHINE
window testing

The automated window testing machine provides an efficient solution to end of production line window and door testing.



This chamber tests windows and doors up to 10 feet in height and 10 ½ feet in width without the use of wood framing or bucks of any kind.  The automated clamping system secures test samples without leaving any scratches or other damage. The chamber accommodates a broad range of window sizes and always maintains an air and water tight seal. The chamber seals to the nailing flange, inner or outer surface of a window frame.

Steel window test wall
STEEL WINDOW TEST WALL
Steel window testing wall

A modular steel wall used to test windows and doors for air leakage, water penetration and structural performance.



A  popular piece of window testing equipment, this modular design allows for expansion without modifications or downtime.  Various sizes of test walls and all levels of control and data-logging are available.  The Window Test Wall allows for quick testing of windows for resistance to water and air leakage, high pressures, pressure cycling, and impact testing.
